BLASTRAC DC655
BLASTRAC DC655
The Blastrac DC 655 is a compact, insulated dust collector that is easy to transport and manoeuvre without giving up heavy-duty performance. It suits large shot blasting and steel blasting machines and combines power, efficiency and productivity in one durable unit.
It carries six M-class cartridge filters, with an optional H14 HEPA filter kit available, and an automatic pulse cleaning system that keeps the filters clear. Dust collection is via a dustbin kit, a Longopac system or a big-bag system.
- Compact and insulated for easy transport and manoeuvring
- Six M-class cartridge filters, optional H14 HEPA kit
- Automatic pulse filter cleaning
- Dustbin kit, Longopac or big-bag collection options
technical specifications
| All Specifications | |
|---|---|
| Motor | |
| Rated Input Power | 6.6 kW |
| Phases | 3 ph |
| Voltage | 400 V |
| Rated Current | 13.7 A |
| Frequency | 50 Hz |
| Power Source | Corded |
| Product Data | |
| Air Flow | 3,200 m³/h |
| Container Capacity | 100 L |
| Dimensions | |
| Product Size Length | 1,731 mm |
| Product Size Width | 757 mm |
| Product Size Height | 1,643 mm |
| Weight (Complete Product w/o Side Packed Articles) | 481 kg |
| Packaging Length | 2,130 mm |
| Packaging Width | 920 mm |
| Packaging Height | 1,820 mm |
| Article Gross Weight | 572,000 g |
